Made in USA
Orem, Utah
Lifetime Guarantee
Unconditional
10 Colors
In-house powder coat
Fully Adjustable
0-6" of lift
3 X-Series Options
Only Core 4x4
The Special Sauce:
HOUSING
- SAE 1045 Solid Steel Forged Housing: This is unequivocally the best carbon alloy steel for this application.
- CNC Machined Housing: Make our parts and bearings dimensionally perfect, eliminating any die wear issues.
BALL STUDS
- SAE 4140 Hot Forged Chromoly Ball Studs: For the strongest possible metallurgy.
- Induction Heat Treated Ball Studs: Provides a very precise heat treatment to the exact depth and location we want it.
- Polished Ball Studs: Built like an anti-friction bearing with extremely precise tolerances.
- Rolled Threads: Made by pressing the shape of the threads into the ball stud instead of cutting. This strengthens the threads instead of weakening them and allows for easy movement of hardware. This ain't no Ikea furniture!
- Step Threads: Allows for very easy movement of hardware on install and superior holding when torqued (installer choice).
BEARING DESIGN
- Rugged Metal to Metal Bearing
BOOTS
- CR Rubber Boots: The most durable material for undercar applications. Resistant to deterioration from road level ozone, oil/gas/engine fluids and extreme heat or cold.
- Internal Seal Boot: The boot is coined onto the ball joint, for superior sealing against contaminants and easier install.
- Accordion Boot: Ideal for high-articulation components, more flexibility means longer life.
FINISH
- E-Coating: Extremely durable electrochemical finishing process
HARDWARE
- Grade 8 - Class 10.9 Hardware: Superior tensile strength.
- Castle Nut: Industry standard where high vibration loads occur.
LUBRICATION
- Pre Threaded Zerk Housing: If you have ever installed a MOOG Ball Joint without a pre-threaded zerk fitting you will understand what a simple but great feature this is. Another installer fav.
- Greaseable: Because it should be.
- Pre-Greased: Just in case you forget, we have you covered.
- Gull Winged Grease Grooves: Allows for improved lubrication disbursement around the ball stud.
- Zerk Fittings: Included for every application.
| Brand | Apex Chassis |
Reviews of Core 4x4
5.0
★
★
★
★
★
132 reviews
DW
Derek Whitfield
Nov 20, 2025
★
★
★
★
★
Solid product, the lifetime warranty sealed the deal for me. Installed on my TJ and the ride quality improved noticeably. Shipping took a bit longer than expected but the parts were worth the wait.
CL
Colten Lockwood
Mar 25, 2019
★
★
★
★
★
Recieved warrenty exchanges for my control arms last night couldnt be happier!!! Lets talk about the arms tho! Great quality arms in multiple styles and colors!!! I purchased the teir 3 short arns for my 98 xj. I can say that they setoff nicely so my 35 inch tires do not rub! As long as you can get a photo or video of broken hardware core will take care of you. The body of the arm is bulletproof. However make sure to maintain and grease the joints regularly as with any greaseable joint and they shouldkast forever. I had a few problems arise a year after purchase and after some troubleshooting spence was able to help get me the correct parts to get back on the road. I recommend this setup to any and all jeepers looking to get away from the stock arm setup. Alltogether i am Very happy with the performace of my control arms!!!! Mechanic and bodyman of 12 years and my first choice for quality control arms!!
CM
Craig MacIver
May 27, 2025
★
★
★
★
★
Got the CAMP version of adjustable control arms and track bars for our 03 TJ with a 3” lift and 33x10.5 KO 2’s.
Super beefy bars, great fit and adjustability.
Friendly advice and support from Korby at CORE 4X4. Good follow up as well.
The ride quality is great as well as the handling. I think it all looks pretty good as well.
MT
Marcus Torres
Jan 15, 2026
★
★
★
★
★
Best control arms I have installed on any of my builds. After running every major manufacturer, Core 4x4 is on par or better than all the high-end companies at a fraction of the cost. Lifetime warranty is the cherry on top.
MP
matthew patterson
May 27, 2025
★
★
★
★
★
Ive used core products for my last two jeeps and now my ram. They’re parts are the absolute best quality youll find ANYWHERE. Top quality products and A+ custom service keeps the as my go Roger for any suspension needs.
JS
Jeffrey Shafer
Jan 22, 2026
★
★
★
★
★
Exceptional customer service. All my questions were asked in a timely manner and parts were replaced when an error occured. I encourage people to make purchases due to their exceptional quality products, but also because of their customer service. Will make additional purchases in the future.
DA
Dastrup Auto
Mar 25, 2019
★
★
★
★
★
I have bought a bunch of sets of arms, track bars and even had custom work done by Core 4x4. Just yesterday, Spence and Cam delivered an awesome cross member they designed and built for me! All of their products have been exceptional! I have personally seen their progression with design changes/updates. They truly take pride in their work and products. Quality control is second to none! They’ve also helped me diagnose issues with different jeeps I’ve had, as well as Dodge/Rams. These guys know their stuff! Really! I trust them whole heartedly and absolutely love their products/quality of work! I’ve referred many people, and will always continue to do so. Keep up the good work Core4x4!
BS
Bailey Smith
Mar 23, 2025
★
★
★
★
★
Core 4x4 excels with precision and service and keeps nothing else higher in mind. Everyone I've met at the company is very honest and down to earth, 10/10 would recommend.
AS
Anthony Snyder
Jun 26, 2025
★
★
★
★
★
Great experience and really great parts
EA
Eric Ahonen
Mar 24, 2021
★
★
★
★
★
Awesome control arms! My mechanic said “ your Jeep is pretty much bulletproof now.” And I just got the tier 1 arms! The people at the core 4x4 shop were really nice too. They were running behind on shipping, (which is understandable) so I decided to go pick it up because it was only an hour drive. They gave me a free $60 hardware kit for the inconvenience. Thanks core 4x4! You guys are awesome!!
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Brand | Apex Chassis |
